Taurox’s hydraulic plate compactors for excavators, or hoe packs, deliver powerful and durable results for projects large and small. Designed for extended component life, these hydraulic compactors will increase your productivity for years to come.
Backed by the best 3-year warranty in the business supported by Accudraulics.
Hydraulic Compaction Plates / Plate Compactor Highlights:
- Available for 2-40 Ton Machines
- Designed for Extreme Operating Conditions
- Industry Leading Compaction Technology
- 3 Year Factory Warranty
- Meets ISO 9001 Standards
- Parts Available
HYDRAULIC COMPACTION PLATE SPECIFICATIONS |
Unit | TCP-20 | TCP-40 | TCP-60 | |
Carrier Weight | ton | 2-6.5t | 5-14t | 16-25t |
Compaction Force | ton | 5 | 10 | 14 |
Operating Pressure | psi | 2130 – 2990 | 2130 – 2990 | 2130 – 2990 |
Oil Flow Range | gpm | 12-18 | 20-25 | 30-45 |
Plate Dimensions | (L x W x T) in | 30 x 12 x 1 | 33 x 25 x 1.25 | 49 x 33 x 1.25 |
Height | in | 29 | 33 | 38 |
Weight | lb | 560 | 1100 | 1985 |
Unit | TCP-80 | TCP-100 | ||
Carrier Weight | ton | 25-35t | 30-40t | |
Compaction Force | ton | 16.5 | 19 | |
Operating Pressure | psi | 2560 – 2990 | 2560 – 2990 | |
Oil Flow Range | gpm | 30 – 45 | 30 – 45 | |
Plate Dimensions | (L x W x T) in | 53 x 37 x 1.375 | 57x 41 x 1.5 | |
Height | in | 38 | 41 | |
Weight | lb | 1985 | 2535 |
