Digga Two Speed Anchor Drives

2-SPEED ANCHOR DRIVES 5,000-7,000FT-LBS

Digga’s two speed screw pile anchor drives can be used for a wider range of applications up to 7,000 ft-lbs.

Developed in conjunction with leading screw/anchor / helical pile installers around the world, Digga brings you the only true anchor drives available – designed and manufactured inhouse specifically for the rigors of application.

Categories: Excavator, Anchor Drives, Construction, Public Works, Utilities

Description

SPECS	5ADT	6ADT	7ADT
NOMINAL TORQUE (FT LBS)	4,745	5,847	7,357
MOTOR TYPE	EATON	EATON	EATON
MAX PRESSURE – DO NOT EXCEED	3500 PSI @ 27 GPM
MAX FLOW – DO NOT EXCEED	53 GPM @1700 PSI
MAX HORSE POWER	55	55	55
PRESSURE RELIEF VALVE	INCLUDED	INCLUDED	INCLUDED
ENERGY CONTROL VALVE	INCLUDED	INCLUDED	INCLUDED
STANDARD OUTPUT SHAFT	2.5″ HEX	2.5″ HEX	2.5″ HEX

WEIGHT (LBS)	400 LBS	400 LBS	400 LBS
OVERALL LENGTH (IN)	37.9″	37.9″	37.9″
DIAMETER (IN)	13.4″	13.4″	13.4″

Digga Two Speed Anchor Drives
